Tamron Fixed-Focal 13FG06IR-SQ

1/3 6mm F/1.2 IR with connector

Product Specifications

Focal Length

6mm
Iris Range

F/1.2 - 360
Iris Operation

Auto-Iris (DC)
Focus Operation

Manual
Mount

CS
1/3" Angle of View (wide/telephoto)

46.5° x 34.6°
1/4" Angle of View (wide/telephoto)

34.6° x 25.9°
Focusing Range

0.2m ~ INF
Effective Diameter (Front/Rear Lens)

Ø14.7mm/Ø9.6mm
Back Focus (in air)

8.92mm
Operating Voltage

Open 2.5V, Close 0.5V
Exit Pupil Position

-281.9mm
Registration of Drive coil

190Ω ± 10% (20°C)
Registration of Control coil

465Ω 10% (20°C)
Max Voltage

6V
Weight

38 grams
Operating Temperature

-20°C ~ +60°C

Tamron Fixed-Focal 13FG06IR-SQ
